Features:

- Single Inlet & Double Outlets

- Magnetically operated, normally closed

- Instantaneous operate when electric power energize ≦ 1 sec

- When electric power failure, valve closes ≦ 1 sec

- Mounting in any position, in pipe or on bracket

- Maximum Inlet Pressure: 35 mbar ~ 50 mbar

- Flow Capacity (1" W.C. Pressure Drop):

   Double Outlets: 65,000 BTU/hr (Each Outlet)

- Operating Temperature: 0°C~145°C

- Customization:

．Solenoid coil operation AC/DC voltage

．Gas inlet and outlet thread dimension
