Features:

- Single Inlet & Outlet

- Automatic shut-off valve

- Instantaneous operate when electric power energize ≦ 1 sec

- When electric power failure, valve closes ≦ 1 sec

- Two safety shut-off valve

- Mounting Position: Any position except coil facing downwards

- Maximum Inlet Pressure: 3.5 kPa ( 35 mbar )

- Flow Capacity (1" W.C. Pressure Drop):

  Natural Gas: 21,000 BTU/hr

  Liquefied Petroleum Gas: 33,000 BTU/hr

- Operating Temperature: -10°C~80°C

- Customization:

．Solenoid coil operation with 120Vac or 230Vac voltage

．Gas inlet and outlet thread dimension
