Features:

- Single Inlet & Outlet

- Magnetically operated, normally closed

- Instantaneous operate when electric power energize ≦ 1 sec

- When electric power failure, valve closes ≦ 1 sec

- Two safety shut-off valve

- Mounting in any position, in pipe or on bracket

- Maximum Inlet Pressure: 7.0 kPa ( 70 mbar )

- Flow Capacity (1" W.C. Pressure Drop):

  Single Outlet: 65,000 BTU/hr

- Operating Temperature: -10°C~80°C

- Customization:

．Solenoid coil operation AC/DC voltage

．Gas inlet and outlet thread dimension
