Features:

- Single Inlet & Triple Outlets

- Magnetically operated, normally closed

- Instantaneous operate when electric power energize ≦ 1 sec

- When electric power failure, valve closes ≦ 1 sec

- Two safety shut-off valve

- Mounting Position: Any position except coil facing downwards

- Maximum Inlet Pressure: 7.0 kPa ( 70 mbar )

- Flow Capacity at 0.25 kPa ( 2.5 mbar ) Pressure Drop:

  Outlet 1 ≧ 750 L/h

  Outlet 2 ≧ 650 L/h

  Outlet 3 ≧ 550 L/h

- Operating Temperature: -10°C~80°C

- Customization:

．Solenoid coil operation AC/DC voltage

．Gas inlet and outlet thread dimension
