Features:

- Multifunctional gas control with two automatic shut-off valves

- Two automatic solenoid shut-off valves with safety valve

  sequencing function for direct burner ignition operation.

- Gas regulation function

- Servo pressure regulator and slow opening (optional).

- Main outlet pressure adjustment (optional)

- Default Outlet Pressure Adjustment Range:

  NG 2"~5" W.C. / LPG 9"~12" W.C.

- Maximum Inlet Pressure: 50 mbar
- Flow Capacity (1" W.C. Pressure Drop):

  NG: 130,000 BTU/hr / LPG: 200,000 BTU/hr

- Operating Temperature: -24°C~80°C
