Features:

- Millivolt gas control connected with thermostat or

  high-temperature limit switch.

- Three-position outlets and multi-positional capability.

- Gas regulation function

- Pilot valve connection: terminal type combination screw/spade

- Electrical Rating: 250mV~750mV

- Default Outlet Pressure Adjustment Range:

  NG 2"~5" W.C. / LPG 9"~12" W.C.

- Maximum Inlet Pressure: 14" W.C. (0.5 PSI)
- Flow Capacity (1" W.C. Pressure Drop):

  Inlet/Outlet Size: 3/4" NPT

  NG: 260,000 BTU/hr / LPG: 400,000 BTU/hr

  Inlet/Outlet Size: 1/2" NPT

  NG: 140,000 BTU/hr / LPG: 210,000 BTU/hr

- Operating Temperature: -24°C~80°C
